KTM RC 390 2018 User Manual

WHEELS, TIRES 15
159
15.1 Removing the front wheel
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 112)
– Lift the motorcycle with the front lifting gear. ( p. 113)
K00717-10
Main work
–
Remove screws
1
, take off reflector and push the fender to
the side.
–
Remove screw
2
and pull wheel speed sensor
3
out of the
hole.
–
Loosen screw
4
.
–
Loosen screws
5
.
–
Unscrew screw
4
about 6 turns and press your hand on the
screw to push the wheel spindle out of the axle clamp.
–
Remove screw
4
.
Warning
Danger of accidents Damaged brake discs reduce the
braking effect.
– Always lay the wheel down in such a way that the
brake disc is not damaged.
– Holding the front wheel, withdraw the wheel spindle. Take the
front wheel out of the fork.

KTM RC 390 2018 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Torque	36 Nm @ 7, 000 rpm
Transmission	6-speed
Cooling	Liquid cooled
Rear Suspension	WP monoshock
Front Tire	110/70 ZR17
Rear Tire	150/60 ZR17
Seat Height	820 mm
Ground Clearance	178.5 mm
Fuel Tank Capacity	10 liters
Dry Weight	147 kg
Engine Type	Single Cylinder, 4-Stroke
Power	43 hp (32 kW) @ 9, 000 rpm
Fuel System	Electronic Fuel Injection
Frame	Steel trellis frame
Front Suspension	WP upside-down Ø 43 mm
Front Brake	320 mm disc
Rear Brake	230 mm disc, single-piston caliper
ABS	Two-channel Bosch 9MB ABS
