23 TECHNICAL DATA 181

Screw, footrest bracket M6 7 Nm (5.2 lbf ft) –

Screw, front fairing M6 6 Nm (4.4 lbf ft) –

Screw, front fairing structure on head-

light bracket

M6 7 Nm (5.2 lbf ft) –

Screw, front fender on axle clamp M6 7 Nm (5.2 lbf ft) –

Screw, front fender, top side M6 7 Nm (5.2 lbf ft) –

Screw, front seat fixing M6 6 Nm (4.4 lbf ft) –

Screw, front spoiler M6 6 Nm (4.4 lbf ft) –

Screw, front spoiler retaining bracket,

rear

M6 6 Nm (4.4 lbf ft) –

Screw, front spoiler retaining bracket,

rear, on engine

M6 6 Nm (4.4 lbf ft) –

Screw, front spoiler, right, on footrest

bracket

M6 6 Nm (4.4 lbf ft) –

Screw, fuel tank trim M6 6 Nm (4.4 lbf ft) –

Screw, ground cable, on frame M6 7 Nm (5.2 lbf ft) –

Screw, handlebar stub M6 8 Nm (5.9 lbf ft) Loctite

243™

Screw, ignition coil M6 9 Nm (6.6 lbf ft) –

Screw, ignition lock M6 11 Nm (8.1 lbf ft) –

Screw, license plate holder on license

plate bracket

M6 7 Nm (5.2 lbf ft) –

Screw, magnetic holder on side stand M6 5 Nm (3.7 lbf ft) Loctite

243™

Screw, mirror holder M6 9 Nm (6.6 lbf ft) –

Screw, passenger seat M6 7 Nm (5.2 lbf ft) –

Screw, radiator air inlet, on frame M6 6 Nm (4.4 lbf ft) –

Screw, radiator holder M6 6 Nm (4.4 lbf ft) –

Questions and Answers:

Need help?

Do you have a question about the KTM RC 390 and is the answer not in the manual?

KTM RC 390 Specifications

General

Displacement	373.2 cc
Max Torque	37 Nm @ 7000 rpm
Transmission	6-speed
Cooling System	Liquid Cooled
Front Suspension	WP APEX 43
Rear Suspension	WP APEX Monoshock
Rear Brake	230 mm disc, single-piston floating caliper
Fuel Tank Capacity	13.7 liters
Seat Height	824 mm
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Frame	Steel Trellis Frame, Powder Coated
Engine Type	Single-cylinder, 4-stroke
Max Power	43.5 PS @ 9000 rpm
Fuel System	Electronic Fuel Injection
Front Brake	320 mm disc, 4-piston radial caliper
ABS	Dual Channel ABS
Dry Weight	172 kg
Front Tire	110/70 R17
Rear Tire	150/60 R17
Ground Clearance	158 mm
