KTM RC 390 User Manual

23 TECHNICAL DATA 182
Screw, rear ABS sensor wheel M6 8 Nm (5.9 lbf ft) –
Screw, rear fender M6 7 Nm (5.2 lbf ft) –
Screw, retaining bracket, EFI control
unit
M6 7 Nm (5.2 lbf ft) –
Screw, seat lock M6 7 Nm (5.2 lbf ft) –
Screw, shift lever linkage M6 11 Nm (8.1 lbf ft) Loctite
®
243™
Screw, side cover M6 6 Nm (4.4 lbf ft) –
Screw, side cover on front fairing M6 7 Nm (5.2 lbf ft) –
Screw, voltage regulator M6 7 Nm (5.2 lbf ft) –
Screw, voltage regulator holder M6 11 Nm (8.1 lbf ft) –
Screw, wheel speed sensor holder M6 7 Nm (5.2 lbf ft) –
Screw, windshield M6 7 Nm (5.2 lbf ft) –
Fitting, engine mounting bracket M8 48 Nm (35.4 lbf ft) –
Remaining nuts, chassis M8 30 Nm (22.1 lbf ft) –
Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –
Screw, chain guard M8 11 Nm (8.1 lbf ft) –
Screw, engine bearer on frame M8 24 Nm (17.7 lbf ft) –
Screw, foot brake lever M8 17 Nm (12.5 lbf ft) Loctite
®
243™
Screw, front brake disc M8 25 Nm (18.4 lbf ft) Loctite
®
243™
Screw, front wheel spindle M8 26 Nm (19.2 lbf ft) –
Screw, fuel tank attachment, rear, on
frame
M8 17 Nm (12.5 lbf ft) –
Screw, horn M8 9 Nm (6.6 lbf ft) –
Screw, main silencer M8 24 Nm (17.7 lbf ft) –
Screw, passenger footrest bracket M8 20 Nm (14.8 lbf ft) Loctite
®
243™

KTM RC 390 Specifications

General

Displacement	373.2 cc
Max Torque	37 Nm @ 7000 rpm
Transmission	6-speed
Cooling System	Liquid Cooled
Front Suspension	WP APEX 43
Rear Suspension	WP APEX Monoshock
Rear Brake	230 mm disc, single-piston floating caliper
Fuel Tank Capacity	13.7 liters
Seat Height	824 mm
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Frame	Steel Trellis Frame, Powder Coated
Engine Type	Single-cylinder, 4-stroke
Max Power	43.5 PS @ 9000 rpm
Fuel System	Electronic Fuel Injection
Front Brake	320 mm disc, 4-piston radial caliper
ABS	Dual Channel ABS
Dry Weight	172 kg
Front Tire	110/70 R17
Rear Tire	150/60 R17
Ground Clearance	158 mm
