91APPENDICES
APPENDICES
MAIN DIMENSIONS
A Above dimensions are based on the machine with KUBOTA original bucket.
A Above dimensions are based on the machine with rubber track.
A Specifications subject to change without notice.
mm
(A) (B) (C) (D) (E) (F) (G) (H) (I) (J)
KX080-3 590 770 2200 7240 5250 4600 3090 1460 4990 7330
(K) (L) (M) (N) (O) (P) (Q) (R) (S)
KX080-3 500 500 2540 2200 7170 1460 6450 2150 2490
