57MAINTENANCE
BGreasing Bucket Pin and Bucket Link Pin
To avoid personal injury:
A First lower all attachments on the ground then
stop the engine and remove the key.
A While greasing, take care not to step on the
bucket teeth.
A When doing excavation work in water, generously
grease the following points. After ending work, grease
again.
Grease the marked grease nipples shown by arrows in the
illustration below.
BChecking Radiator and Oil Cooler
To avoid personal injury:
A Always stop the engine and remove the key
before checking the radiator.
A Wear eye protection when cleaning with
compressed air.
1. Check if the fins and ribs are clogged.
If so clean with compressed air or steam.
2. Check the rubber hoses for damage and replace if
cracked or old. Check if the hose clamps are tight
enough.
(1) Bucket link pin
(2) Fixing pin between arm and bucket
(1) Radiator
(2) Oil cooler
(1) Engine oil cooler
