59REGULAR CHECKS AND MAINTENANCE WORK
REGULAR CHECKS AND MAINTENANCE WORK
To avoid personal injury:
A Do not operate the excavator while putting out
the hands and the body from the windows.
A Do not touch the control levers and the pedals
from outside the cab during the engine
running.
EVERY 50 SERVICE HOURS
BDraining the Water from the Fuel Tank
To avoid personal injury:
A Before draining the water from the fuel tank, be
sure to stop the engine and remove the key.
A Do not smoke during inspection.
1. Open the side cover.
2. Open the drain cock.
BDraining Water Separator
1. Open the side cover.
2. When the separated water is entering the sediment
cup, the red float moves upwards.
When the float reaches the line, close the cock so that
no fuel can run out. Now loosen the ring nut, and
remove the cup and empty completely.
3. Finally, do not forget to open the cock and close the
side cover after the cup has been reinstalled.
(1) Drain cock
(1) Ring nut
(2) Cup
(3) Cock
(4) Float
(5) Line
