69REGULAR CHECKS AND MAINTENANCE WORK
EVERY 500 SERVICE HOURS
Do all 50, 100 and 250 hour servicing at the same time.
BDrive Unit Oil Change(First Oil Change of
the 100 hours)
To avoid personal injury:
A Lower all attachments to the ground, stop the
engine and remove the key before undertaking
the oil change.
1. Rotate the track so that the drain plug of the drive unit
is in the bottom position.
2. Remove the drain plug to let the oil run out. Screw in
and tighten the drain plug again and fill with gear oil
through the oil check port.
3. Fill oil until it overflows out of the oil check port.
Oil change
- first oil change after 100 hrs
- then every 500 hrs
- or at least once a year
4. Use prescribed gear oil SAE 90.
(1) Dozer cylinder boss
(2) Dozer linkage boss
(1) Oil check port
(2) Drain plug
(3) Oil filling port
Gear oil volume approx. 1.35 L
