Kubota KX080-3 - Second Service Port Operation

39EXCAVATOR OPERATION
BSecond Service Port Operation
C Service Port Max. Flow Volume
A When the service port is not used for a long period, dirt particles can settle in the lower part of the service port lines.
When the plugs on the service port lines are removed to connect attachments, drain approx. 100 cc (3.4 oz) of oil per
side before making connections.
For hammer choices, contact your dealer.
Max. Flow Volume
(Theoretical L/min.)
67
Max. pressure
MPa (kgf/cm )
20.6 (210)
