5INSTRUMENT PANEL AND CONTROL ELEMENTS
B Control Pedals and Levers
DEPICTED CONTENTS
(1) Drive lever (left)
(2) Lock lever*
(3) Control lever for front attachments (left)
(4) Drive pedal
(5) Drive lever (right)
(6) Control lever for front attachments (right)
(7) Dozer control lever
(8) Throttle potentiometer
(9) Boom swing pedal
D When the lock lever pulled up prevents inadvertent machine movement.
