REGULAR CHECKS AND MAINTENANCE WORK78
AIR CONDITIONER
BCleaning Air Filter
Open the cover under the operator’s seat and remove the
filter cover, remove the air filter.
To avoid personal injury:
A Wear eye protection.
C Cleaning the air filter
A Normal use
Blow air from the opposite direction to the filter's
normal air flow.
A Do not hit the filter. If the filter becomes deformed, dust
may enter into the air-conditioner, which may cause
damage and malfunction.
A Pressure of compressed air must be under 205 kPa
(2.1 kgf/ , 30 psi).
A If the filter is very dirty, replace the air filter.
BChecking Air-Conditioner Condenser
Check air conditioner condenser to be sure it is clean from
debris.
(1) Air filter
(2) Filter cover
(1) Filter (A) "AIR-CONDITIONER AIRFLOW"
(1) Air conditioner condenser
