Kubota KX080-4 User Manual

CHECKS BEFORE START22
BOpening/Closing of Front CAB Window
To avoid personal injury:
A Keep hands and feet away from the area
between front window and CAB frame.
Otherwise the operator risks serious pinching
or crushing injuries.
A Other persons should stay clear when opening
the window.
To open and close the front window, take the steps below.
1. Push the lock levers beside grip.
2. Hold the grips tightly with both hands. Pull the grip
slightly upward and toward yourself to let the
windshield slide inward.
3. Pull the windshield all the way to the lock at the back
of CAB.
4. To close the window, take the reverse steps 3, 2 and 1.
BOpening/Closing of Side CAB Window
1. Pull the grip to release the lock and pull side window
open to the rear or to the front.
2. To close the side window, slide it forward or backward
until the lock snaps in at the window frame.
BEmergency Hammer
To avoid personal injury:
A When breaking the window pane, close your
eyes and cover them with an arm.
The emergency hammer is for breaking a window pane in
order to quick escape from the cab, should the window not
open.
(1) Lock lever
(2) Grip
(1) Grip
(1) Emergency hammer

Kubota KX080-4 Specifications

General

Engine Power	66.4 HP
Bucket Capacity	0.28 m3 / 0.37 yd3
Max Digging Depth	15 ft 1 in
Max Reach	7320 mm / 24 ft
Max Dumping Height	5, 280 mm
Max Digging Radius	7, 660 mm
Width	7 ft 2 in
Transport Height	8 ft 4 in
Travel Speed	5.0 km/h
