Kubota KX080-4 - Every 250 Service Hours; Greasing Front Attachments (Without Bucket Pin and Boom Swing Fulcrum)

79REGULAR CHECKS AND MAINTENANCE WORK
EVERY 250 SERVICE HOURS
Do all 50 hour servicing at the same time.
BGreasing Front Attachments (without
Bucket Pin and Boom Swing Fulcrum)
To avoid personal injury:
A First lower all attachments on the ground then
stop the engine and remove the key.
A While greasing, take care not to step on the
bucket teeth.
A When doing excavation work in water, generously
grease the following points. After ending work, grease
again.
Grease the marked grease fittings shown by arrows in the
illustration below.
(1) Boom bottom linkage
(2) Arm bottom linkage
(3) Boom cylinder boss
(4) Boom cylinder pin
(5) Arm cylinder pin
(6) Bucket cylinder pin
(1) Swing cylinder boss
(1) Dozer cylinder boss
(2) Dozer linkage boss
(1) Dozer cylinder boss
(2) Dozer linkage boss
