21CHECKS BEFORE START
BHeater Switch
Turn the starter switch to the "RUN" position and turn the
heater switch clockwise, the heater fan will be activated
and the cabin will start to warm up. The heater has three
position.
A During summer, turn the heater valve clockwise to
close the valve.
BOpening/Closing of CAB Door
1. Unlock the CAB door and pull the knob. Open the CAB
door fully until fixed into place.
2. To close the CAB door, push the release lever down
and close the door.
3. When leaving the excavator, always lock the door.
(1) Heater switch
(2) Temperature control dial
(1) Door knob (outside)
(1) Release lever
(2) Door knob (inside)
(A) Push down
