S-12
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG WSM
DIESEL ENGINE
ENGINE BODY (Continued)
W1119370
Item Factory Specification Allowable Limit
Balancer Shaft Journal 1 to Balancer Shaft
Bearing 1 (Balancer Model Only)
Balancer Shaft Journal 1
Balancer Shaft Bearing 1
Oil Clearance
O.D.
I.D.
0.0300 to 0.111 mm
0.00119 to 0.00437 in.
43.934 to 43.950 mm
1.7297 to 1.7303 in.
43.980 to 44.045 mm
1.7315 to 1.7340 in.
0.20 mm
0.0079 in.
–
–
Balancer Shaft Journal 2 to Balancer Shaft
Bearing 2 (Balancer Model Only)
Balancer Shaft Journal 2
Balancer Shaft Bearing 2
Oil Clearance
O.D.
I.D.
0.0300 to 0.111 mm
0.00119 to 0.00437 in.
41.934 to 41.950 mm
1.6509 to 1.6515 in.
41.980 to 42.045 mm
1.6528 to 1.6553 in.
0.20 mm
0.0079 in.
–
–
Balancer Shaft Journal 3 to Balancer Shaft
Bearing 3 (Balancer Model Only)
Balancer Shaft Journal 3
Balancer Shaft Bearing 3
Oil Clearance
O.D.
I.D.
0.020 to 0.094 mm
0.00079 to 0.0037 in.
21.947 to 21.960 mm
0.86406 to 0.86456 in.
21.980 to 22.041 mm
0.86536 to 0.86775 in.
0.20 mm
0.0079 in.
–
–
Piston Pin Bore I.D. 25.000 to 25.013 mm
0.98426 to 0.98476 in.
25.05 mm
0.9862 in.
Top Ring to Ring Groove
[D1803-M-DI]
[V2403-M-DI]
Clearance 0.050 to 0.090 mm
0.0020 to 0.0035 in.
0.20 mm
0.0079 in.
Second Ring to Ring Groove
[D1503-M], [D1703-M]
[D1803-M], [V2003-M]
[V2203-M], [V2403-M]
[V2403-M-T], [V2403-M-DI-T]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
[V2403-M-BG]
Clearance 0.0930 to 0.128 mm
0.00367 to 0.00503 in.
0.20 mm
0.0079 in.
Second Ring to Ring Groove
[D1803-M-DI], [V2403-M-DI]
Clearance 0.0780 to 0.110 mm
0.00307 to 0.00433 in.
0.20 mm
0.0079 in.
Oil Ring to Ring Groove
[D1503-M], [D1703-M]
[D1803-M], [V2003-M]
[V2203-M], [V2403-M]
[V2403-M-T], [V2403-M-DI-T]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
[V2403-M-BG]
Clearance 0.020 to 0.060 mm
0.00079 to 0.0023 in.
0.15 mm
0.0059 in.
Oil Ring to Ring Groove
[D1803-M-DI], [V2403-M-DI]
Clearance 0.030 to 0.070 mm
0.0012 to 0.0027 in.
0.15 mm
0.0059 in.
To Next Page
