S-13
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG WSM
DIESEL ENGINE
ENGINE BODY (Continued)
W1086708
Item Factory Specification Allowable Limit
Top Ring
[D1503-M], [V2003-M], [V2403-M-T]
[D1803-M-DI], [V2403-M-DI]
[V2403-M-DI-T]
[V2003-M-BG], [V2003-M-T-BG],
Ring Gap 0.20 to 0.35 mm
0.0079 to 0.013 in.
1.25 mm
0.0492 in.
Top Ring
[D1703-M], [D1803-M]
[V2203-M], [V2403-M]
[D1703-M-BG], [V2203-M-BG]
[V2403-M-BG]
Ring Gap 0.25 to 0.40 mm
0.0099 to 0.015 in.
1.25 mm
0.0492 in.
Second Ring
[D1503-M], [D1703-M]
[D1803-M], [V2203-M]
[V2403-M]
[D1803-M-DI], [V2403-M-DI]
[D1703-M-BG], [V2003-M-BG]
[V2203-M-BG], [V2403-M-BG]
Ring Gap 0.30 to 0.45 mm
0.012 to 0.017 in.
1.25 mm
0.0492 in.
Second Ring
[V2003-M], [V2403-M-T], [V2403-M-DI-T]
[V2003-M-T-BG]
Ring Gap 0.40 to 0.55 mm
0.016 to 0.021 in.
1.25 mm
0.0492 in.
Oil Ring
[D1503-M], [D1703-M]
[D1803-M], [V2003-M]
[V2203-M], [V2403-M], [V2403-M-T]
[V2403-M-DI-T]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
[V2403-M-BG]
Ring Gap 0.25 to 0.45 mm
0.0099 to 0.017 in.
1.25 mm
0.0492 in.
Oil Ring
[D1803-M-DI], [V2403-M-DI]
Ring Gap 0.20 to 0.40 mm
0.0079 to 0.015 in.
1.25 mm
0.0492 in.
Connecting Rod Alignment – 0.05 mm
0.002 in.
Piston Pin to Small End Bushing
Piston Pin
Small End Bushing
Oil Clearance
O.D.
I.D.
0.014 to 0.036 mm
0.00056 to 0.0014 in.
25.004 to 25.011 mm
0.98441 to 0.98468 in.
25.025 to 25.040 mm
0.98524 to 0.98582 in.
0.15 mm
0.0059 in.
–
–
Crankshaft Alignment – 0.02 mm
0.0008 in.
Crankshaft Journal to Crankshaft Bearing
1
Crankshaft Journal
Crankshaft Bearing 1
Oil Clearance
O.D.
I.D.
0.0400 to 0.118 mm
0.00158 to 0.00464 in.
59.921 to 59.940 mm
2.3591 to 2.3598 in.
59.980 to 60.039 mm
2.3615 to 2.3637 in.
0.20 mm
0.0079 in.
–
–
KiSC issued 07, 2008 A
