KUHN FC302G - Preparing the Tractor

6. - Putting into service
FC302G - FC302GI - FC352G
33
KN270BGB_F
Mower conditioner
6.2.2 Preparing the tractor
The machine adapts to tractors fitted with a 2-point
hitch coupler category 2 or 3.
Select the tractor speed of 540/min.
or
Select the tractor speed of 1000/min.
The tractor PTO must rotate at a speed of 540 or
1000 rpm.
The tractor must be equipped with:
- 1 double acting hydraulic outlet.
- 1 single acting hydraulic outlet.
Check that the tractor's authorized gross
weight as well as its lift capacity and
maximum weight per axle are not exceeded:
See section:
- Safety / Safety instructions /
Precautions when driving on public
roads.
M1
abcd
T
1
T2
M2
The tractor must be fitted with lower link
stabilizers.
Hitch pin parallelism
- Adjust tractor lift rods so that hitch pins are parallel
to the ground.
A
A
