6. - Putting into service
KN270BGB_F
Mower conditioner
If this is not the case:
- Mark length (H) to cut when the transmission is the
maximum overlap position.
- Shorten the guard tubes and the transmission
tubes by the same length.
- Bevel and clean the tubes.
- Grease the inside of the outer tube.
Never operate the PTO shaft at an angle X
exceeding 30°.
X
X
To avoid serious accidents, the PTO drive
shaft guards must be properly in place and
fixed with the chains provided.
