6. - Putting into service
FC302G - FC302GI - FC352G
41
KN270BGB_F
Mower conditioner
- Loosen nuts to release friction discs (a).
- Let the friction discs slip for a few seconds (b).
- Tighten nuts to the dimension (L) of 34 mm (1.34’’).
a
b
c
L
Do not fully tighten springs to prevent
damage on drive elements.
Loosen at least by 1/2 turn.
