8. - Instructions for work
FC302G - FC302GI - FC352G
49
KN270BGB_F
Mower conditioner
- Open the mowing unit lift cylinder lock valves (1).
- Activate mowing unit lift cylinders to fully raise the
machine.
1
1
Opened position (1).
Closed position (2).
1
2
- Remove R-clip (1).
- Remove safety bar (2).
- Open drawbar shift cylinder lock valve (3).
- Activate the transport/work cylinder control valve
in the "pivot into work" position.
3
1
2
