8. - Instructions for work
KN270BGB_F
Mower conditioner
Selecting the conditioning surface of the comb
The comb can be turned over to modify the
conditioning intensity:
- A more aggressive side for gramineous plants.
- A softer side for more delicate varieties.
Adjustment:
- Remove screw (1).
- Remove lever (2).
- Remove spacer (3).
- Turn over comb to the other position.
- Clean and reassemble the unit:
• Torque setting: 5 daN.m (37 lbf ft).
3
1
2
