FC302G - FC302GI - FC352G
86
10. - Maintenance and storage
KN270BGB_F
Mower conditioner
Before checking that the discs rotate freely by hand:
FC352G
- Turn off the engine, remove ignition key
and wait until all moving parts have come
to a complete stop.
- Regularly check the cutterbar oil level:
• Place the cutterbar in horizontal position (with
regards to X and Y axis).
• Remove filler plug (1) and (2) as well as their
seals.
• Check, through openings, that the oil height
corresponds to a value (h) comprised between
2 mm (0.08’’) and 3 mm (0.11’’).
• Top up if necessary.
• Clean and reinstall filler plugs and their seals (1)
and (2). (Replace if necessary).
If in doubt as to the oil quantity contained in
the cutterbar, fully drain and refill cutterbar
respecting recommended oil quantity and
quality.
