10. - Maintenance and storage
GMD24-GMD28 / HD
65
KN226BGB_A
Disc mower
- Never use an oil of viscosity SAE 90 in the
cutterbar.
From the transport position:
- For safety reasons, hook check chain as
high as possible.
- Place a container of sufficient capacity under drain
plug.
- Remove filler plug (1) and its washer.
- Unscrew drain plug (2) and its seal.
- Allow oil to drain completely.
- Wait for dripping to stop.
- Clean and reinstall drain plug (2) and its washer.
Replace if necessary.
- Pour the correct oil quantity and quality through the
opening of the filler plug.
Checking cutterbar oil level:
• The oil must reach the lower edge of the filling
hole (1).
- Clean and reinstall filler plug (1) and its washer.
Replace if necessary.
1
2
