KUHN PROPUSH 2000 Series - Wheels and Tires

PROPUSH 2000 SERIES
46
9. - Inspections and adjustments
7N018KUS_A
Box Spreader Trailer Type
9.1.1 Wheels and tires
Wheel nut torque:
- 8 bolt hub with 5/8’’ grade 5 hex lug nut, torque to
170 ft lbs (23 daNm).
- 10 bolt hub with 3/4’’ grade 5 hex lug nut, torque to
300 ft lbs (41 daNm).
Inflation pressure:
Wheel lug nuts should be checked after the first
few loads and re-torqued if necessary. Torque
should be checked on a monthly basis.
Tire size Maximum pressure
21.5 X 16.1 36 PSI (2.48 bar)
16.5 X 16.1 36 PSI (2.48 bar)
275-80R X 22.5 80 PSI (5.52 bar)
385-65R X 22.5 80 PSI (5.52 bar)
425-65R X 22.5 80 PSI (5.52 bar)
600-55 X 22.5 39 PSI (2.69 bar)
Damage to rim may occur if lug nuts are not
kept tight.
