BACKREST
Backrest height
The backrest height can be changed by fitting the telescopic tubes
into another position in the backrest tubes. If this setting option is
insucient, the telescopic tubes can be replaced.
Adjusting the height of standard backrests
Diculty:
Tools:
à 3, 4, 6 8, 10
Push the backrest cover upwards and remove the bolt on
both sides.
Push the push handles upwards or downwards until you reach
the required height. Replace the bolt and tighten.
i
If this setting range is insucient, use new push handle tubes.
i
If the backrest height was changed considerably, a new backrest
cover may have to be fitted.
Adjusting the height of hook and loop adjustable back-
rests
Diculty:
Tools:
à 3, 4, 6 8, 10
Remove backrest cover and move the hook and loop bands until
bolt is visible.
Remove bolt and move the push handle tube to the required
height.
Insert bolt into the appropriate hole and tighten.
i
If the backrest height is changed considerably, the push handles
must be replaced. An additional hook and loop band may have to
be fitted or one may have to be removed.
1
2
3
4
1
2
3
