10.FINAL REDUCTION/
TRANSMISSION SYSTEM
10-2
Mongoose/KXR 250
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• The transmission system can be serviced with the engine installed in the frame.
• When replacing the drive shaft, use a special tool to hold the bearing inner race for this operation.
SPECIFICATIONS
Specified Oil: GEAR OIL SAE 90#
Oil Capacity: At change : 0.3 liter
At disassembly : 0.4 liter
TORQUE VALUES
Transmission case cover bolt 2.4～3.0kgf-m
TROUBLESHOOTING
Engine starts but motorcycle won‘t move
• Damaged transmission
• Seized or burnt transmission
Oil leaks
• Oil too rich
• Worn or damaged oil seal
