4. LUBRICATION SYSTEM
4-3
Mongoose/KXR 250
Bolts
ENGINE OIL/OIL FILTER
OIL LEVEL AND OIL CHANGE
Refer to the “ENGINE OIL” section in the
chapter 3 to check the oil level and
replacement and oil filter cleaning.
OIL PUMP
REMOVAL
Remove the right crankcase cover and the
A.C. generator flywheel. (Refer to the “A.C.
GENERATOR/FLYWHEEL” section in the
chapter 16)
Remove the starter clutch gear. (Refer to the
“STARTER CLUTCH” section in the
chapter 18)
Remove the two bolts and oil separator
cover.
Pry the circlip off and remove the oil pump
driven gear, then remove the oil pump drive
chain and oil driven sprocket.
Oil Separator Cove
To Next Page
