3. INSPECTION/ADJUSTMENT
3-11
Mongoose/KXR 250
DRIVE BELT
Remove the left crankcase cover.
Inspect the drive belt for cracks, scaling,
chipping or excessive wear.
Measure the V-belt width
Service limit: 22mm
Replace the drive belt if out of specification.
BRAKE PADS INSPECTION
A wear indicator is provided on each brake.
The indicators allows checking of brake
pads wear. Check the position of the
indicator. If the indicator reaches the wear
limit line, to replace the pads.
BRAKE FLUID INSPECTION
Check if the fluid level is below the lower
level mark through the inspection window.
Drive Bel
t
Front Calipe
r
Rear Calipe
r
Inspection Window (R/L Brake Lever)
