5. FUEL SYSTEM
5-4
Mongoose/KXR 250
FUEL TANK
REMOVAL
Remove the seat, right and left side frame
cover (See page 2-3) and center frame cover
(See page 2-5).
Switch the fuel valve “OFF”.
Disconnect the fuel tube from carburetor and
remove two screws at the fuel valve holder.
Remove the two bolts and two nuts at the
fuel tank, then remove the fuel tank.
INSTALLATION
Reverse the “FUEL TANK REMOVAL”
procedures.
FUEL VALVE
REMOVAL
Remove the screw and then remove control
switch.
Disconnect all fuel tubes and remove the two
screws, then remove fuel valve.
Warnin
g
N
uts
Fuel Tank
Screw
Fuel Valve
Screws
Fuel Tube
• Keep sparks and flames away from the
work area.
• Wipe off any spilled gasoline.
Control Switch
Screws
Fuel Valve
• Keep sparks and flames away from the
work area.
• Drain gasoline into a clean container.
＊
Fuel Tube Fuel Tubes
