12. COOLING SYSTEM
12-5
Mongoose/KXR 250
RADIATOR DISASSEMBLY
Remove the three bolts and then remove the
fan/shroud from the radiator.
Check fan motor by battery.
CHECK THERMOSTATIC SWITCH
When coolant temperature lower then
85~90℃ the thermostatic switch OFF.
When coolant temperature over 85~90℃
the thermostatic switch ON.
RADIATOR ASSEMBLY
Install the fan shroud on the radiator with
the three bolts.
RADIATOR INSTALLATION
Reverse the “RADIATOR REMOVAL”
procedures.
Fill the radiator with coolant. (
Ö
3-20)
Connect the vent tube to the radiator filler.
After installation, check for coolant leaks.
Bolts
If you want to refill the coolant , the
following procedure must be checked.
1. Please make the radiator filler and the
air vent tube to be separated.
2. Then start the engine , filled in the
coolant till the coolant flowed out
from the air vent tube.
3. Put the air vent tube on.
＊
Thermostatic Switch
