KYMCO Mongoose/KXR 250 User Manual

15. REAR WHEEL/AXLE/SUSPENSION
15-5
Mongoose/KXR 250
Inspect the brake disk
Cracks/damage → Replace.
Inspect the brake disk splines.
Wear/damage → Replace.
Loosen the driven chain (refer to the
“DRIVE CHAIN SLACK ADJUSTMENT”
section in the chapter 3) and remove the two
bolts at the drive sprocket (refer to the
chapter 6), then disconnect the drive chain
from the driven sprocket.
Remove the rear axle from right side.
Driven Sprocke
t
Rear Axle
S
p
lines
Tap the axle and with a rubber hammer,
this will avoid damage the axle thread.
＊
Bolts
Drive Sprocket Cove
r
Bolts
Drive Sprocke
t
