16. BATTERY/CHARGING SYSTEM/
A.C. GENERATOR
16-9
Mongoose/KXR 250
Remove the flywheel with a flywheel puller.
Flywheel puller E003
INSTALLATION
Reverse the “REMOVAL” procedures.
Install the flywheel, washer and tighten the
nut.
Torque: 5.5～6.5kgf-m
Install the oil through guide and spring.
Install the A.C. generator onto the right
crankcase cover and tighten the bolts.
Torque: 0.8～1.0kgf-m
Install the right crankcase cover.
Special
Flywheel Pulle
‧Before installation, check and make
sure that the inside of the flywheel is
not contaminated.
‧Make sure install the flywheel onto
the crankshaft by aligning the key on
the crankshaft with the groove in the
flywheel.
＊
Key
Groove Washe
