6. ENGINE REMOVAL
6-2
Mongoose/KXR 250
ENGINE REMOVAL
Drain engine oil and transmission oil.
(Refer to chapter 3)
Remove frame covers and exhaust pipe.
(Refer chapter 2)
Remove the carburetor. (Refer to chapter 5)
Disconnect the oil recycle tube at the
cylinder head cover.
Disconnect the water hose from water pump
cover.
Remove the bolt at the thermostat and
disconnect the thermosensor wire, then
disconnect the thermostat from the cylinder
head.
Remove the bolt at the drive select arm,
then disconnect the drive select arm from
engine assembly.
Oil Recycle Tube
Water Hose
Bol
t
Thermosensor Wire
Thermosta
t
Drive Select Ar
m
Bol
t
