6. ENGINE REMOVAL
6-4
Mongoose/KXR 250
Remove the A.C.Generator, pulser and gear
change switch couplers.
Disconnect the spark plug cap.
Remove the three bolts and remove the
outlet hose cover.
Unscrew the clamp and then disconnect the
outlet hose from the left crankcase cover.
Unscrew the clamp and then disconnect the
inlet hose from the left crankcase cover.
Gear Change Switch couple
r
A.C.Generator couple
r
Pulser couple
r
Spark Plug Cap
Bolts
Outlet Hose Cove
r
Screw Screw
Outlet Hose
Inlet Hose
