3-6
Basic Operation
Message Display
The following examples explain the messages and icons used on the message display.
Reference
number
Meaning
1 Indicates the current status of the machine. Also displays the title of the current
menu whenever the operation panel is being used.
2 Displays an icon that indicates the currently selected source of paper feed. The
meaning of each icon is as indicated below.
The standard paper cassette is currently selected. When this icon is
displayed as , there is no paper is the cassette.
The paper cassette for the optional paper feeder is currently selected.
When this icon is displayed as , or , there is no paper is the cassette.
F The MP Tray is currently selected. When this icon is displayed as L there
is no paper is the MP Tray.
3 Displays the size of the original(s).
4 Displays the current setting when there is a corresponding menu that can be
selected using the left or right Select keys.
5 Displays the title of the corresponding menu that can be selected using the left
or right Select keys.
6 Displays the number of copies.
7 Displays the paper size to be copied.
8 Displays the number of destinations.
9 Displays the destination.
