2RV/2RW/2RX/2RY/3RA
4-29
8. Release three hooks by using a flat-
head screwdriver (d).
9. Twist two hooks (c) at the front side of
the right cover (b) to release them and
detach the right cover (b).
Figure 4-47
10. Push down the developer release lever
(b).
11. Detach the developer unit (a).
Figure 4-48
a
c
b
d
To Next Page
