2RV/2RW/2RX/2RY/3RA
8-7
(2) High voltage PWB
Connector position
Figure 8-3
PWB photograph
Figure 8-4
YC201
1
CN1
CN2
T
S
M
Gr
PGND2
D
PGND1
