Kyocera Ecosys P2235dw

2RV/2RW/2RX/2RY/3RA
4-2
(4) Screening of the toner container
Look at the screening film on the brand protection seal affixed to the toner container through the windows
of the validation viewer.
Look at the screening film through two windows to check the genuineness.
A black-colored band when seen through the the anti-counterfeit film portion left side window ( mark).
A shiny or gold-colored band when seen through the anti-counterfeit film portion right side window
( mark).
When seen as the above, it is genuine. Otherwise (e.g. both seen in gold), it is a counterfeit.
Figure 4-1
The anti-counterfeiting film portion has three slits as the figure below and it can not reused.
Figure 4-2
Validation viewer Validation viewer
( marking)
A shiny or gold-colored band when
seen through the right side window
A black-colored band when
seen through the left side window
( marking)
Brand
protection
seal
Brand
protection
seal
Three cut parts at the red circle section
