Kyocera Ecosys P2235dw

2RV/2RW/2RX/2RY/3RA
4-53
14. Release two hooks (b) at the rear side
of the left cover (a).
15. While tilting the left cover (a), detach it
in the direction of the arrow.
Figure 4-94
16. Twist three hooks (b) at the rear side of
the right cover (a) to detach it.
17. Release two hooks by using a flat-head
screwdriver (c).
Figure 4-95
b
a
a
b
c
