Kyocera Ecosys P2235dw

2RV/2RW/2RX/2RY/3RA-1
4-65
15. Release three hooks by using a flat-
head screwdriver (d).
16. Twist two hooks (c) at the front side of
the right cover (b) to release them and
detach the right cover (b).
Figure 4-117
17. Remove two screws(M3x8S tight)(a)
and detach the USB earth plate (b).
18. Disconnect all the connectors and
FFCs from the main/engine PWB(c).
Figure 4-118
a
c
b
d
a
b
c
