Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA
5-3
(The first page)
The first line: "FW-Update"
Page number/total page number and upper and
lower key icon are displayed.
The second line: "Completed" (Completion message)
(The second and subsequent page)
The first line: "CTRL", (the character string applicable to the
update target)
Page number/total page number and upper and lower
key icon are displayed.
The second line: (updated version)
*: When there is no applicable master file, "No Change" is dis-
played.
*: "*" is displayed after the update target name when it has been
skipped.
7. Check if the new firmware versions are displayed.
8. Unplug the power cord and disconnect the USB memory.
9. Connect the power cord and turn the power switch off after checking that "Ready to copy" is displayed.
In case of any error (the error which can not read a file), the process is interrupted immediately and the com-
pletion is displayed without executing the subsequent firmware update.
(The first page)
The first line: "FW-Update"
Page number/total page number and upper and lower
key icon are displayed.
The second line: "Error"
(The second and subsequent page)
The first line: "ENGN", (the character string applicable to the
update target)
Display page number/total page number, upper and
lower key icon
The second line: "Error", error code
Error code
Code Error contents Code Error contents
0000 Others S000 Other signature verification error
0100 There is no master file. S001 The signature verification file is insuffi-
cient.
0200 Master file version discrepancy N001 Unable to connect the network *2
(There is no target to update.)
03xx *4 There is no download file (No.xx).
04xx *4 File (No.xx) check sum discrepancy N002 Can not connect to the network *3
(There is the target to update.)
05xx *4 File (No.xx) preparation failure
FW-Update 1/10
Completed
[CTRL] 2/10
2RB_2000.001.005
[ENGN] 9/10
No Change
[CTRL] 2/10
2S1_2000.001.005
FW-Update 1/10
Error
[ENGN] 10/10
Error 0100

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
