Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
1-2
Separation system Curvature separation + discharger needle (grounded) : except
100 V model
Curvature separation + discharger needle (DC voltage
impressed) : 100 V model only
Cleaning system Counter blade
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system Sliding belt + foam press roller system
Heat source: halogen heater
Abnormal temperature preventing device: 2 thermocat
Operation Panel 2-line LCD LED
Memory 256 MB
Interface USB Interface Connector: 1 (Hi-Speed USB)
USB Port: 1 (Hi-Speed USB)
Network Network interface: 1
(10 BASE-T/100 BASE-TX/1000 BASE-T)
Wireless LAN Wireless LAN
support Only
- Wireless LAN
support Only
-
Operating
Environment
Temperature 10 to 32.5°C/50 to 90.5°F
Humidity 10 to 80%
Altitude 3,500 m/11,482 ft maximum
Brightness 1,500 lux maximum
Dimension (W × D × H) 14.77" × 15.48" × 10.71" 375 × 393 × 272 mm
Weight (without toner container) Approx. 30.9 lb/Approx. 14 kg
Space Required (W × D) (Using multi purpose tray) 14.77" × 28.47" 375 × 723 mm
Power Source AC100 V, 50/60 Hz, 9.5A
AC120 V, 60 Hz, 8.1A
AC220 to 240V, 50 Hz, 4.2A
*1 Up to upper limit height line in the cassette.
Item Description
40 ppm model 35 ppm model
P2040dw P2040dn P2235dw P2235dn

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
