Kyocera Ecosys P2235dw

2RV/2RW/2RX/2RY/3RA-3
7-43
J0501: Cassette no feed
Condition: The sensor detection is unstable.
When feeding from cassette 1, the paper leading edge reaches the registration sensor but it does not turn on
after the feed clutch turns on.
10 Replacing the PF main
PWB
The PF main PWB is
faulty.
Replace the PF main PWB.
11 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.
Step Check description Assumed cause Measures Reference
1 Checking the connection The connector is not prop-
erly connected or the wire
is faulty.
Clean the terminal of the fol-
lowing wire connectors and
reconnect the connectors. If
there is no continuity, replace
the wire.
• Registration sensor (on the
high voltage PWB) - Main/
engine PWB (YC16)
2 Checking the registration
sensor
The registration sensor
does not operate properly.
Clean the registration sensor
and reconnect the connector.
If not repaired, replace the
high voltage PWB (including
the registration sensor).
3 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.
Step Check description Assumed cause Measures Reference
