Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-55
4 (In case paper is conveyed
in skew) Checking the
press spring
The front/rear PF feed
roller pressure balance is
not proper.
Reattach the PF feed roller
press spring. If deformed,
correct or replace it.
5 (In case paper skews)
Checking the conveying
guide
The paper is caught with
the conveying guide.
Reattach the conveying
guide. If there is a burr on the
conveying side of the convey-
ing guide, remove it or
replace the conveying guide.
6 Checking the PF feed
roller and drive gear
The conveying perfor-
mance is lowered or slip-
page occurs (rotation not
smooth).
Clean the PF feed roller sur-
face. If worn down, replace it.
If foreign objects adhere to
the drive gear, remove them
and if damaged, replace it.
7 Checking the PF cover The PF cover is deformed. Check if the PF cover is
closed securely. If not closed
due to deformation, replace
it.
8 Checking the paper The cut-end of the paper is
crushed.
Fan the paper well and load it
by reversing the paper direc-
tion
9 Checking the paper The paper leading edge is
bent.
Remove the bent paper.
10 Checking the paper Paper is curled downward
or wavy.
Correct or replace paper. If
difficult to replace, re-load
paper by switching top and
bottom ends or turning it over.
11 Checking the paper Unspecified papers are
used.
Explain to the user to use the
paper within the specifica-
tions.
12 Checking the paper foreign objects are on the
paper.
Remove the paper with for-
eign objects.
13 Checking the connection The connector is not prop-
erly connected or the wire
is faulty.
Clean the terminal of the fol-
lowing wire connectors and
reconnect the connectors. If
there is no continuity, replace
the wire.
• PF feed sensor (PF1) - PF
main PWB (YC7)
• PF main PWB (YC5)(PF1) -
Drawer connector
• Drawer connector - Main/
engine PWB (YC17)
14 Checking the PF feed sen-
sor
The PF feed sensor does
not operate properly.
Clean the PF feed sensor,
reattach it and reconnect the
connector. If not repaired,
replace it. (Paper feeder 1)
15 Replacing the PF main
PWB
The PF main PWB is
faulty.
Replace the PF main PWB.
(Paper feeder 1)
Step Check description Assumed cause Measures Reference

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
