Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA
8-2
Connector access point
YC1: In-machine temperature sensor, Fuser pressure release motor, In-machine fan motor, Eject solenoid
YC2: Temperature humidity sensor, Waste toner sensor, Thermopile
YC3: Polygon motor
YC5: Eraser
YC6: MP paper sensor, Paper sensor, Container relay PWB
YC7: Eject fan motor
YC8: Inter lock switch
YC9: Main motor
YC10: Developer clutch, Feed clutch, Registration clutch
YC14: Toner sensor
YC16: Registration sensor, High voltage PWB
YC17: PF-1100
YC19: Fuser pressure release sensor, Rotation detection sensor, Eject sensor, Fuser terminal thermistor
YC20: Low voltage power supply PWB
YC21: MP solenoid
YC23: Power switch
YC501: USB
YC502: EtherNet
YC503: SD
YC504: Wi-Fi
YC505: APC PWB
YC507: Operation panel PWB(LCD model only)
YC507: Operation panel PWB(TSI model only)
YC510: USB PWB
YS1: EEPROM
Connec-
tor
Pin Signal I/O Voltage Description
YC1 1 +24V6FA - 24 V DC 24 V DC power source
2 EXISOLRE I 0/24 V DC Eject solenoid drive
3 PREMOTRE- I/O 0/24 V DC Pressure release motor drive
4 PREMOTRE+ I/O 0/24 V DC Pressure release motor drive
5 FAN1MOTRE I 0/24 V DC/
about12V
Left side fan drive
6 +24V6FA(FAN) - 24 V DC 24 V DC power (When fan stops, the out-
put is turned off)
7 GND - 0 V DC Ground
8 INTTMP I Analog In-machine temperature sensor output
YC2 1 HUMCLK O 0/3.3 V DC(pulse) Outside machine humidity sensor clock
2 HUMDATA_ I 0/3.3 V DC(pulse) Outside machine humidity sensor clock
signal
3 TMPDATA I Analog Outside temperature sensor clock signal
4 GND - 0 V DC Ground
5 FUSTMPSE1O I Analog Thermopile output 0
6 GND - 0 V DC Ground
7 +3.3V4LS - 3.3 V DC 3.3 V DC power supply
8 FUSTMPSE1A I Analog Thermopile output A

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
