Kyocera Ecosys P2235dw

2RV/2RW/2RX/2RY/3RA
8-14
Connector access point
YC1: Main/Engine PWB
Connec-
tor
Pin Signal I/O Voltage Description
YC1 1 LED2 O 0/3.3 V DC LED2 cathode
2 LED3 O 0/3.3 V DC LED3 cathode
3 LED1 O 0/3.3 V DC LED1 cathode
4 LED7 O 0/3.3 V DC LED7 cathode
5 LED0 O 0/3.3 V DC LED0 cathode
6 KEY0 O 0/3.3 V DC KEY0 signal
7 LED4 O 0/3.3 V DC LED4 cathode
8 KEY3 O 0/3.3 V DC KEY3 signal
9 LED5 O 0/3.3 V DC LED5 cathode
10 GND - 0 V DC Ground
11 LED8 O 0/3.3 V DC LED8 cathode
12 +3.3V2 - 3.3 V DC 3.3 V DC power supply
13 KEY2 O 0/3.3 V DC KEY2 signal
14 LED6 O 0/3.3 V DC LED6 cathode
15 KEY1 O 0/3.3 V DC KEY1 signal
16 BUZZER O 0/5 V DC(pulse) buzzer
17 +5V2 - 5 V DC 5 V DC power
