Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-1
3-9
Part name table
*1:Wi-Fi model only, *2:LCD model only, *3:LED model only
No. Name used in service manual Name used in parts list Part. No.
2
Main/Engine PWB
PARTS PWB MAIN ENGINE ASSY SP
PARTS PWB MAIN ENGINE ASSY EU SP
PARTS PWB MAIN ENGINE ASSY SP
PARTS PWB MAIN ENGINE ASSY EU SP
PARTS PWB MAIN ENGINE ASSY SP
PARTS PWB MAIN ENGINE ASSY EU SP
PARTS PWB MAIN ENGINE ASSY SP
PARTS PWB MAIN ENGINE ASSY EU SP
302RV94080
302RV94090
302RW94010
302RW94020
302RX94010
302RX94020
302RY94010
302RY94020
3 Wi-Fi PWB *1 PARTS WiFi UNIT SP 302R794010
4
Power source PWB
PARTS UNIT LOW VOLTAGE 100V SP
PARTS UNIT LOW VOLTAGE 230V SP
302RV94210
302RV94220
5 Eraser PWB PARTS PWB ERASER ASSY SP 302RV94110
6 USB PWB PARTS PWB FRONT PWB ASSY SP 302RV94120
7
High-voltage PWB
PARTS UNIT HIGH VOLTAGE SP
PARTS UNIT HIGH VOLTAGE J SP
302RV94190
302RV94200
9 Operation panel PWB *2 PARTS PWB P PANEL ASSY SP 302RX94030
11 Grid PWB (DK-1150) (302RV93010)
12 APC PWB (LK-1150) (302RV93070)
13 Operation panel PWB *3 PARTS PWB L PANEL ASSY SP 302RV94100
14 PF main PWB PARTS PWB PF CONT ASSY SP 303RA94010

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
