2-15
Installing and Setting up the Machine > Default Settings of the Machine
Network Setup (LAN Cable Connection)
The machine is equipped with network interface, which is compatible with network protocols such as TCP/IP (IPv4),
TCP/IP (IPv6), NetBEUI, and IPSec. It enables network printing on the Windows, Macintosh, UNIX and other platforms.
Set up TCP/IP (IPv4) to connect to the Windows network.
TCP/IP Settings
IPv4 setting
Set up TCP/IP (IPv4) to connect to the Windows network.
1
Display the screen.
[Menu] key > [▲] [] key > [Network] > [OK] key > [▲] [] key > [TCP/IP Settings] >
[OK] key > [▲] [] key > [IPv4 Setting] > [OK] key
2
Configure the settings.
When setting the static IP address
1 [▲] [▼] key > [DHCP] > [OK] key > [▲] [▼] key > [Off] > [OK] key
2 [▲] [▼] key > [IP Address] > [OK] key
3 Set the IP address.
4 Select the [OK] key.
5 [▲] [▼] key > [Subnet Mask] > [OK] key
If user login administration is enabled, you can only change the settings by logging in with administrator privileges.
If user login administration is disabled, the user authentication screen appears. Enter a login user name and
password, and select [Login].
The factory default login user name and login password are set as shown below.
ECOSYS P6035cdn ECOSYS P7040cdn
Login User Name: 3500 4000
Login Password: 3500 4000
Ask your network administrator for the IP address in advance, and have it ready when you configure this setting.
In the following cases, set the IP address of DNS server on the Command Center RX.
Setting the IP Address of the DNS Server, refer to the following:
Command Center RX User Guide
• When using the host name with "DHCP" setting set to "Off"
• When using the DNS server with IP address that is not assigned by DHCP automatically.
You can set any value between 000 and 255.
Use the numeric keys or select the [▲] or [▼] key to enter a number.
Select the [◄] or [►] key
to move the position being entered, which is shown highlighted.
To Next Page
