Kyocera FS-1060DN - Page 106

2M2/2M3
2-3-2
Connector Pin Signal I/O Voltage Description
YC5 1 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB
Connected to
APC PWB
2 LONBN O 0/3.3 V DC Sample/hold signal
3 LDCONT O 0/3.3 V DC LD voltage control signal
4 PDN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
5 GND - - Ground
6 LDENBN O 0/3.3 V DC Laser output enable signal
7 VIDEO O 0/3.3 V DC (pulse) Video data signal (-)
8 VIDEON O 0/3.3 V DC (pulse) Video data signal (+)
YC6 1 KEY1 I 0/3.3 V DC KEY1: On/Off
Connected to
Operation
panel PWB
2 KEY2 I 0/3.3 V DC KEY2: On/Off
3 KEY3 I 0/3.3 V DC KEY3: On/Off
4 LED1 O 0/3.3 V DC LED1: On/Off
5 LED2 O 0/3.3 V DC LED2: On/Off
6 LED3 O 0/3.3 V DC LED3: On/Off
7 GND - - Ground
YC12 1 GND - - Ground
Connected to
Power
source PWB
2 GND - - Ground
3 +24V1 I 24V DC 24 V DC power from PSPWB
4 PUSHSW I 0/3.3 V DC power SW signal
5 HEATREM O 0/3.3 V DC Heater On/Off signal
6 RELAY O DC0V/24V Relay signal
7 PSSLEEPN O DC0V/24V Sleep mode signal
8 ZCROSS O 0/3.3 V DC (pulse) Zero-cross signal
9 +24V2 I 24V DC 24 V DC power from PSPWB
10 +24V2 I 24V DC 24 V DC power from PSPWB
YC13 1 GND - - Ground
Connected to
high voltage
PWB
2 MISENS I 0/3.3 V DC Charge current signal
3 TCNT O PWM Transfer current signal
4 MCNT O PWM Main charger output control signal
5 RTHVDR O 0/3.3 V DC Transfer (reverse) bias output signal
6 HVCLK O 0/3.3 V DC (pulse) Developer bias clock signal
7 +24V3 O 24V DC 24 V DC power to PSPWB
