Kyocera FS-1060DN User Manual

2M2/2M3
1-4-6
(3) Self diagnostic codes
If the part causing the problem was not supplied, use the unit including the part for replacement.
Release is performed by power supply OFF/ON.
Code Contents Causes
Check procedures/
corrective measures
0100 Backup memory read/write
error (NOR)
Flash returns an abnormal
status.
Defective flash
memory.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
0120 MAC address data error
For data in which the MAC
address is invalid.
Defective flash
memory.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
0190 Backup memory error
(engine)
Unable to read the main PWB
IC.
Defective flash
memory.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
0630 Scan DMA error
Unable to transfer DMA.
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
2000 Main motor error
Pulse is not detected after
1000msec.
Motor won’t stabilize after
300msec.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
main motor and Relay PWB (YC4)
Relay PWB and main PWB (YC14).
Defective drive
transmission sys-
tem of motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective motor. Replace the main motor.
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
4000 Polygon motor synchronize
error
Polygon motor is not stabi-
lized within 15 s since the
motor is activated.
After polygon motor is stabi-
lized, the ready signal is not
detected for 7 s continuously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Polygon motor and main PWB (YC17)
Defective polygon
motor.
Replace the laser scanner unit
(see page 1-5-12).
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
4200 BD stability error
The BD signal is not detected
for 1000 ms after processing
the compulsion lighting.
At the interrupt in VSYNC, the
BD error is detected continu-
ously for 10 times in 400 ms
intervals.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Laser scanner unit (YC1) and main PWB
(YC5)
Defective APC
PWB.
Replace the laser scanner unit
(see
page 1-5-12).
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).

Kyocera FS-1060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Processor model	ARM926EJ
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Total number of input trays	2
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (printing)	134 W
Product color	Black, White
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Compatible operating systems	Windows Vista 32/64 bit\\r Windows XP 32/64 bit\\r Windows 7 32/64 bit\\r Windows Server 2003\\r Windows Server 2008 32/64 bit\\r Mac OS X

Weight and Dimensions

Dimensions (WxDxH)	358 x 276 x 241 mm
