6000 Broken fuser heater
The temperature does not
reach 100° C/212 °F after the
fuser heater lamp has been
turned on continuously for 30
s.
At the time of 20 degrees or
less from specified tempera-
ture,the fuser temperature
does not rise by 2 degrees or
more after the fuser heater
lamp has been turned on con-
tinuously for 8 s.(during ready
or during print)
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
fuser heater lamp and Power source PWB
(YC102).
Fuser thermostat
triggered.
Replace the fuser unit (see page 1-5-6).
Defective fuser
heater.
Replace the fuser unit (see page 1-5-6).
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
6020 Abnormally high fuser
thermistor temperature
Fuser thermistor detects a
temperature higher than
210°C/410°F for 3 s
Deformed connec-
tor pin.
If the I/F connector pins of the fuser unit and
the main unit are deformed owing to foreign
matters, such as paper dusts, replace the
connectors or the units including the con-
nectors.
Shorted fuser
thermistor.
Replace the fuser unit (see page 1-5-6).
Defective power
source PWB.
Replace the power source PWB
(see page 1-5-7).
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
6030 Broken fuser thermistor
wire
Average input AD given by the
thermistor is less than 2 for
300msec.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Fuser unit and main PWB (YC15)
Broken fuser
thermistor wire.
Replace the fuser unit (see page 1-5-6).
Fuser thermostat
triggered.
Replace the fuser unit (see page 1-5-6).
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
6400 Fixing control zerocross
signal error
The ZCROSS signal does not
reach the main PWB for more
than 2 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Power source PWB (YC103) and main PWB
(YC12)
Defective power
source PWB.
Replace the power source PWB
(see page 1-5-7).
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-7).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-1060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Processor model	ARM926EJ
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Total number of input trays	2
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (printing)	134 W
Product color	Black, White
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Compatible operating systems	Windows Vista 32/64 bit\\r Windows XP 32/64 bit\\r Windows 7 32/64 bit\\r Windows Server 2003\\r Windows Server 2008 32/64 bit\\r Mac OS X

Weight and Dimensions

Dimensions (WxDxH)	358 x 276 x 241 mm
